SIA-118 Series Tri-Temp Test Handler
Whether you are testing at room, cold or hot temperatures, our tri-temp test handlers are suited for a wide range of applications, from the basic to the most stringent and demanding test requirements. The SIA-118 series offers an open platform for packages from 3 x 3 mm up to 100 x 50 mm at a temperature range from -55 °C to +125 °C and optional full temperature range from -60 °C to +175 °C. Offering easy and flexible configuration, this tri-temperature handler supports both Kelvin and PTB contactors for SOIC, QSOP, SSOP, QFN, TO, MEMS and other custom packages. It is ideally suited for Engineering, Qualification Lot, and small-to-medium production run with easy migration to full production capability. This is a popular model for custom applications with very low NRE.
